Make the Shift

Stoll's Spraying Equipment Pty Ltd is Australia's fastest growing boomspray manufacturer.

Did you know... All S Series sprayers are fitted with an automatic rate control and automatic section control system to suit your existing
GPS equipment. UV Stabilised polyethylene tank with large sump for complete drainage and smooth interior for easy chemical decontamination. Tank designed for maximum chassis stability.

Forward sloping tank with front sump keeps weight on the tractor as the sprayer empties. Tank and chassis are designed to give high ground clearance, yet still retain a low centre of gravity. Top quality TeeJet controls are fitted including 430 series 12v electric ball valves with stainless
steel ball, electric regulating valve & 801 flowmeter.

Trailer & boom are sandblasted before being primed with the highest quality zinc shield primer & then powdercoated. This process provides excellent chemical resistance with a hard rich finish and ensures that your sprayer will look good, years into the future. Section valves are mounted on the boom centre rack, rather than at the front of the sprayer to cut down on unnecessary lengths of hose for easier
decontamination, neater installation & quicker on/off time of booms. The workzone at the front of the sprayer features only two clearly labelled taps which makes operating the S Series a breeze. No fuss. No stress. No trouble.

Simply Better.

S Series available in 6 sizes:

S10: 10,000lt     |     S8: 8000lt     |     S6: 6000lt    |    S5: 5000lt     |     S4: 4000lt     |     S3: 3000lt

S Series Sprayer

S Series sprayers are reliable, strong machines. Designed and built with strength, simplicity and ease of use in mind, all sprayers in our S Series range feature heavy duty construction, simple plumbing design and layout with the highest quality components fitted. These features ensure
that Stoll S Series sprayers are the most reliable machines on the market. Along with a large list of standard features you also have the option to customise your sprayer any way you choose.

S6, S8 and S10 Series

S6, S8 and S10 Series made specifically for larger operators. 6000lt, 8000lt and 10,000lt tank with the option of 24m and 36m booms.

Axle/Wheels: Single axle is standard with large 20.8 x 42” wheels (S6), 20.8 x 46” wheels (S8) or 650/85R 38” wheels (S10), heavy duty Maxus axle with airbag suspension results in a very smooth ride. Heavy duty twin leaf trailing arms gives longer boom and chassis life, this suspension system ensures that the boom has the smoothest ride possible. Axle features heavy duty 10 stud hubs. 3m centres are available as an option.

Boom: All steel construction (350 grade) heavy duty hydraulic booms range in size from 24m to 36m. All booms feature hydraulic parallelogram lift with nitrogen accumulator suspension and hydraulic fold together with individual hydraulic wing tilt and hydraulic bi-fold, meaning that the outer wing can be folded in hydraulically to spray at a narrower width. S6,S8 & S10 booms are plumbed with 7 x sections as standard.

Hydraulic floating drawbar (S8 & S10 only): The drawbar is connected to the chassis via two hydraulic rams which are plumbed into a nitrogen accumulator. This works as a suspension system for the drawbar. The front platform on the S8 and S10 has also been designed so that you can forklift a 1000L shuttle on and off with ease.

S3, S4 and S5 Series

S3, S4 & S5 Series made specifically for medium sized operators. 3000L, 4000L & 5000lt tank with the option of 18m to 24m booms (S3) or 18m to 36m booms (S4/S5).

Axle/Wheels: Single axle is standard with large 16.9 x 34” wheels (S3), 18.4 x 38” wheels (S4), 18.4 x 38” (S5) heavy duty Maxus axle with coil spring suspension (airbag suspension available as an option) results in a very smooth ride. Heavy duty twin leaf trailing arms gives longer boom and chassis life, this suspension system ensures that the boom has the smoothest ride possible. Axle features heavy duty 10 stud hubs. 3m centres are available as an option.

Boom: All steel construction (350 grade) heavy duty hydraulic booms range in size from 18m to 36m. All booms feature hydraulic parallelogram lift with nitrogen accumulator suspension and hydraulic fold, together with individual hydraulic wing tilt and hydraulic bi-fold meaning that the outer wing can be folded in hydraulically to spray at a narrower width. All S3 & S4 booms are plumbed with 5 x sections as standard.
